High Accuracy Pressure Transducer 0-300 psi for Industrial Automation, Hydraulic Systems & Process Control - Reliable Pressure Sensor for Water, Oil & Gas Applications
Free shipping on all orders over $50
7-15 days international
9 people viewing this product right now!
30-day free returns
Secure checkout
22435788
Description
'Pressure Transmitter, Wetted Materials - Transmitters Stainless Steel, Range Values - Transmitter 0 to 300, Range Units - Transmitter psi, Accuracy - Transmitter +/-0.50 Percent Full Scale, Electrical Connections - Transmitter 4 Pin M12 Connector, Power Required - Transmitters 9 to 36VDC, Process Connection Size - Transmitter 7/16 In.-20, Process Connection Type - Transmitter SAE Male, Output - Transmitter 4 to 20mA DC, Operating Temp. - Transmitter -40 Degrees to 257 Degrees F'
Features
Price For Each Output 4 to 20 mA at 12 to 30VDC Includes Instructions Manufacturers Warranty Length 1 yr. Process Connection Size - Transmitter 7/16"-20 Operating Temp. -40 to 257 F Range 0 to 300 psi Power Required 9 to 36VDC Range Units - Transmitter psi Accuracy - Transmitter +/-0.50% Full Scale Item Pressure Transmitter Max. Pressure (PSI) 600 NEMA Rating -
Calibration Certificate - Power Required - Transmitters 9 to 36VDC Electrical Connections - Transmitter 4 Pin M12 Connector Thermal Error +/-3% (-4 Degrees to 185 Degrees F) Process Connection Type - Transmitter SAE Male For Use With - Features - Range Values - Transmitter 0 to 300 Process Connection 7/16-20 SAE Male Wiring Entry - Transmitter 1/2" FNPT Wetted Materials Stainless Steel
Operating Temp. - Transmitter -40 Degrees to 257 Degrees F Housing 304 Stainless Steel Wetted Materials - Transmitters Stainless Steel Output - Transmitter 4 to 20mA DC Accuracy +/-0.5% Full Scale Compatible With Any Process Compatible with 316Stainless Steel Electrical Connections M12, No Connector Loop Resistance Dependent on Loop Supply Voltage Transmitter Type Pressure Transmitter
Country of Origin (subject to change) United States
